What is this?

GLES Mod lets Minecraft: Java Edition 1.21.1 run on Android against the device's native OpenGL ES 3.2 driver.

On Android, Minecraft Java normally runs through a translation layer: the game issues desktop OpenGL 3.2+ calls, and a shim (GL4ES, ANGLE, Zink, …) translates every one of them into GLES. That works, but the per-call cost is paid on the hottest paths in the frame — tens of thousands of glUniform* / glBindTexture / glVertexAttribPointer calls per frame.

This project takes a different route: it ships a GL library that is the implementation. Launchers such as FCL dlopen a GL library and hand it to LWJGL; instead of pointing at a translation layer, you point at ours.

flowchart LR
    A["Minecraft Java<br/>desktop GL 3.2+ calls"] --> B{"Which GL library?"}
    B -- "GL4ES / ANGLE / Zink" --> C["translation layer<br/>(per-call cost)"]
    C --> D["GLES driver"]
    B -- "GLES Mod" --> D

Features

Requirements

Verified device: Xiaomi houji / SM8650 / Adreno 750 / Android 16 / GLES 3.2.

Installation

Two pieces, deliberately separated:

1. The NeoForge mod — glesmod-1.0.0.jar

Drop it into mods/. This is the cross-launcher form: it handles capability reporting, mod compatibility detection, and status output. It is advisory only — on its own it cannot replace the GL library.

2. The FCL renderer plugin — glesmod-renderer-plugin.apk

Install it as an FCL renderer plugin, then select it in FCL's Renderer settings. This is where the actual GL implementation lives. FCL dlopens the GL library by path — no LD_PRELOAD, no inline hooking, no launcher modification. That is why this project is a renderer plugin by construction.

The native library is not inside the mod jar. It lives in the plugin APK. If you only install the jar, nothing changes — and that is the most common "I installed it and nothing happened".

Building

./gradlew build                                # NeoForge mod jar

Native library and plugin APK need the Android NDK:

./build-all.ps1 -WithPlugin                    # everything: jar + .so + apk
./build-all.ps1                                # jar + .so only

⚠️ -WithPlugin is not implied. Without it the APK is not rebuilt, so the device keeps loading the previous native library even though the code changed. There is a gate for this (native/tools/check_artifact_freshness.py) because it has already cost one full device test round.

Toolchain: JDK 21, Android SDK (aapt2/d8/zipalign/apksigner), Android NDK 27.x (Clang, CMake, Ninja, glslc). See docs/build-environment.md.

Testing

The converter is the risky part, so it is tested the hardest — entirely on the host, in seconds, with no device needed:

py -X utf8 native/tools/run_all_gates.py

Attribution matters as much as the result: every fix is verified by an A/B control build (-DGLESMOD_NO_RULE_*) so we know the change caused the improvement, and every converter rule has a required-string marker so a stale binary can never masquerade as a fixed one.

Compatibility

Also runs alongside Iris, Veil, Flywheel, Sable, Create + Aeronautics and friends. See docs/p2-07-compatibility-matrix.md.

Known limitations

Stated plainly, because pretending otherwise helps nobody:

• No compute / SSBO / tessellation. GLES 3.2 does not have them. Shaders that need them are skipped with a logged reason — not silently broken.
• Multi-Draw is unavailable, so Sodium chunk rendering falls back to per-draw submission: a small performance cost.
• Not every possible shader compiles. The converter covers the constructs we have met and can prove; when it cannot convert, it forwards the original source and dumps both versions to glesmod/native.log so the failure is diagnosable rather than mysterious.
• No EGL takeover. We provide GL only and reuse the launcher's existing context, deliberately avoiding a second translation stack on top of ANGLE.

Documentation

License

LGPL-3.0-or-later — see LICENSE.

LGPL rather than MIT, deliberately: this project's role is to replace a system library, so it should remain replaceable. If you ship a modified libgl_gles.so, the changes need to come back.

Third-party components, build-time dependencies, and material that is deliberately kept out of the repository are listed in THIRD-PARTY-NOTICES.md.

Minecraft is a trademark of Mojang Studios / Microsoft. This is an unofficial third-party project, not affiliated with or endorsed by Mojang Studios or Microsoft. This project contains no Minecraft game code or assets.

中文

这是什么？

GLES Mod 让 Minecraft: Java 版 1.21.1 在 Android 上直接跑在设备的 原生 OpenGL ES 3.2 驱动之上。

Android 上的 Minecraft Java 通常要穿过一层翻译：游戏发出桌面 OpenGL 3.2+ 调用， 由 GL4ES / ANGLE / Zink 之类的兼容层逐条翻译成 GLES。这能跑，但代价落在每一帧 最热的路径上 —— 每帧数万次 glUniform* / glBindTexture / glVertexAttribPointer，每次都要过一次翻译。

本项目走另一条路：提供一个「本身就是 GL 实现」的 GL 库。 FCL 等启动器通过 dlopen 加载一个 GL 库并交给 LWJGL —— 不要指向兼容层， 而是指向我们。

flowchart LR
    A["Minecraft Java<br/>桌面 GL 3.2+ 调用"] --> B{"用哪个 GL 库？"}
    B -- "GL4ES / ANGLE / Zink" --> C["兼容层<br/>（逐次翻译开销）"]
    C --> D["GLES 驱动"]
    B -- "GLES Mod" --> D

特性

环境要求

已验证设备：Xiaomi houji / SM8650 / Adreno 750 / Android 16 / GLES 3.2。

安装

两件东西，刻意分开：

1. NeoForge 模组 —— glesmod-1.0.0.jar

放进 mods/。这是跨启动器的形态：负责能力上报、优化模组兼容检测、状态输出。 它只做辅助 —— 单独装它无法替换 GL 库。

2. FCL 渲染器插件 —— glesmod-renderer-plugin.apk

作为 FCL 渲染器插件安装，然后在 FCL 的 Renderer 设置里选中它。 真正的 GL 实现在这里。FCL 是按路径 dlopen GL 库的 —— 不需要 LD_PRELOAD、 不需要 inline hook、不需要改启动器。这也是本项目天然就是一个渲染器插件的原因。

原生库不在模组 jar 里，而在插件 APK 里。 只装 jar 不会有任何变化 —— 这是最常见的「我装了但没反应」。

构建

./gradlew build                                # NeoForge 模组 jar

原生库与插件 APK 需要 Android NDK：

./build-all.ps1 -WithPlugin                    # 全部：jar + .so + apk
./build-all.ps1                                # 只构建 jar + .so

⚠️ -WithPlugin 不会自动生效。不带它时 APK 不会被重建， 于是代码虽然改了，设备加载的仍是上一个原生库。 已为此设立门禁（native/tools/check_artifact_freshness.py）—— 这个坑已经实实在在浪费过一轮真机测试。

工具链：JDK 21、Android SDK（aapt2/d8/zipalign/apksigner）、 Android NDK 27.x（Clang、CMake、Ninja、glslc）。 详见 docs/build-environment.md。

测试

转换器是风险最高的部分，所以对它测得最狠 —— 全部在主机上、几秒钟、不需要设备：

py -X utf8 native/tools/run_all_gates.py

归因和结果同样重要：每项修复都用 A/B 对照构建（-DGLESMOD_NO_RULE_*） 验证，确保是我们改好的而不是本来就好的；每条转换规则都有标记字符串， 确保陈旧的二进制不可能冒充已修复的版本。

兼容性

亦可与 Iris、Veil、Flywheel、Sable、机械动力 + 航空学 等共存。 见 docs/p2-07-compatibility-matrix.md。

已知限制

如实列出 —— 掩饰对谁都没好处：

• 不支持 compute / SSBO / 曲面细分。GLES 3.2 没有这些能力。需要它们的着色器会被 记录原因后显式跳过，而不是静默地坏掉。
• Multi-Draw 不可用，Sodium 的区块渲染退化为逐次提交：有少量性能损失。
• 并非所有着色器都能转换。转换器覆盖的是我们遇到过并能证明的构造；转换失败时 它会转发原始源码，并把两份都写进 glesmod/native.log， 让失败可诊断而不是成谜。
• 不接管 EGL。我们只提供 GL、复用启动器已建好的上下文， 刻意避免在 ANGLE 之上再叠一层翻译。

许可证

LGPL-3.0-or-later —— 见 LICENSE。

选 LGPL 而不是 MIT 的理由：本项目的角色是替换一个系统库， 因此它应当保持可被替换。如果你分发修改过的 libgl_gles.so，改动需要回馈。

第三方成分、构建期依赖，以及刻意排除在仓库之外的素材， 逐项列在 THIRD-PARTY-NOTICES.md。

Minecraft 是 Mojang Studios / Microsoft 的商标。 本项目为非官方第三方项目，与 Mojang Studios 及 Microsoft 无任何关联，亦未获其认可或赞助。本项目不包含 Minecraft 的游戏代码或资源。
