Mirage

A Minecraft Fabric mod for incremental, real-time dimension region synchronization between a main server and one or more mirror servers.

中文说明

Features

Architecture

flowchart LR
    subgraph Main["Main Server"]
        MS[ServerLevel world]
        RH[RegionHasher SHA-256]
        SS[MirageSyncServer<br/>Netty TCP :25566]
        SM[MainServerTask broadcasts hashes]
    end

    subgraph Mirror["Mirror Server"]
        MR[ServerLevel world]
        DC[DeltaComparator diff]
        FT[FileTransferManager atomic move]
        SC[MirageSyncClient TCP client]
        MA[MirrorApplyTask applies changes]
    end

    MS -->|"flush save"| RH
    RH -->|"hash map"| SS
    SS -.->|"HASH_LIST_RESP"| SC
    SC -->|"FILE_SYNC_START"| DC
    DC -->|"file list"| SS
    SS -.->|"FILE_CHUNK"| SC
    SC -->|"write temp mca"| FT
    FT -->|"atomic move"| MR
    MA -->|"kick players"| MR
    MA -->|"clear cache"| MR

Sync sequence (mirror-initiated pull):

sequenceDiagram
    participant M as Mirror Server
    participant S as Main Server

    M->>S: HANDSHAKE (authToken)
    S-->>M: OK

    M->>S: HASH_LIST_REQ
    S->>S: flush world, save chunks
    S->>S: compute SHA-256 for all .mca files
    S-->>M: HASH_LIST_RESP (dimension + hash map)

    M->>M: diff with local hashes
    alt no differences
        M-->>S: SYNC_DONE (no changes)
    else files differ
        M->>S: FILE_SYNC_START (list of changed files)
        loop each file
            S-->>M: FILE_CHUNK (512 KB segments, base64)
        end
        S-->>M: SYNC_DONE
    end

    M->>M: kick all players in dimension
    M->>M: force-save + disable saving
    M->>M: force-unload all chunks + clear region cache
    M->>M: atomic-move temp files → region dir
    M->>M: clear region cache again
    M->>M: re-enable world saving
    M->>M: sync complete

Requirements

Installation

1. Build the mod

   ./gradlew build

The output jar is at build/libs/mirage-<version>.jar.

1. Install on both main and mirror servers

   • Place the jar into each server's mods/ folder.
   • Both servers must run the same Minecraft version (1.21.11).

2. First launch

   • Start the server once. config/mirage.json is auto-generated.
   • Stop the server and edit the config (see below).
   • Restart the server.

Configuration

Config file: config/mirage.json, created on first launch.

Main server

{
  "mode": "main",
  "syncCooldownSeconds": 30,
  "mainServer": {
    "port": 25566,
    "authToken": "replace-with-a-secure-random-string"
  }
}

Mirror server

{
  "mode": "mirror",
  "syncCooldownSeconds": 30,
  "mirrorServer": {
    "mainIp": "main-server-ip-or-hostname",
    "mainPort": 25566,
    "authToken": "replace-with-a-secure-random-string",
    "targetDimensions": [
      "minecraft:overworld"
    ],
    "autoSyncEnabled": false,
    "autoSyncIntervalMinutes": 30
  }
}

Configuration fields

Warning: authToken must be identical on both servers — connections are rejected otherwise. Change the default value change-me to a secure random string before use.

Note: Changes to network settings (port, mainIp, mainPort) require a server restart.

Commands

All admin-level commands require permission level OPERATORS.

Main server commands

Mirror server commands

Note: Players in the target dimension on the mirror server will be kicked during sync.

Project Structure

src/main/java/xyz/tofumc/
├── Mirage.java                         # Mod entrypoint, lifecycle
└── mirage/
    ├── command/
    │   └── MirageCommand.java          # /mirage command tree (brigadier)
    ├── config/
    │   ├── ConfigManager.java           # JSON config read/write
    │   └── MirageConfig.java            # Config POJO with defaults
    ├── hash/
    │   ├── RegionHasher.java            # SHA-256 all .mca files in a dimension
    │   ├── DeltaComparator.java         # Hash diff → files to download/delete
    │   └── FileTransferManager.java     # Chunked write + atomic move
    ├── network/
    │   ├── protocol/
    │   │   ├── MessageType.java        # Enum: HANDSHAKE, HASH_LIST_REQ, ...
    │   │   ├── MirageProtocol.java     # Binary encode/decode (ByteBuf codec)
    │   │   ├── MessagePayloads.java     # Record-based payload definitions
    │   │   └── MirageFrameDecoder.java # 4-byte big-endian length framing
    │   ├── server/
    │   │   ├── MirageSyncServer.java   # Netty NIO server, broadcast helper
    │   │   └── ServerHandler.java      # Server-side channel inbound handler
    │   └── client/
    │       ├── MirageSyncClient.java   # Netty TCP client, auto-reconnect
    │       └── ClientHandler.java      # Client-side channel inbound handler
    ├── sync/
    │   ├── SyncState.java              # Sync-in-progress flag + cooldown timer
    │   ├── MainServerTask.java         # Hash computation + broadcast
    │   ├── MirrorApplyTask.java        # Receive + apply files / in-memory chunk patch
    │   └── ScheduledSyncTask.java      # Auto-sync scheduling (mirror side)
    ├── util/
    │   ├── HashUtil.java               # SHA-256 digest wrapper
    │   ├── DimensionPathUtil.java      # Dimension ID → region/directory path
    │   ├── RegionFileUtil.java         # .mca filename, chunk offset, NBT I/O
    │   └── SyncLogger.java             # namespaced log helper
    └── world/
        ├── WorldSafetyManager.java     # kick players, force-save, save on/off
        └── ChunkUnloader.java          # unload chunks + clear region cache

Build & Release

Build locally

./gradlew build

Artifact: build/libs/mirage-<version>.jar

The version is read from gradle.properties (mod_version, currently 1.2.0).

CI/CD

Contributing

Bug reports and feature requests are welcome. Please open an issue before submitting a pull request.

Development setup

git clone https://github.com/MRNOBODY-ZST/Mirage.git
cd Mirage
./gradlew build   # verify it compiles

FAQ

Q: Can I run multiple mirrors? Yes. The main server is a TCP server — any number of mirrors can connect simultaneously. Each mirror operates independently.

Q: Does this mod act as a BungeeCord/Velocity proxy? No. Mirage only synchronizes world region files (.mca). It does not proxy player connections or chat. It is a world synchronization tool, not a proxy.

Q: What happens to players during sync? On the mirror server, players in the syncing dimension are kicked with a message and may reconnect immediately (the world is fully saved and consistent). The main server continues to operate normally — players are not affected.

Q: What if the sync is interrupted (e.g. network cut)? File transfer uses atomic temp-file-then-move. If interrupted mid-transfer, the mirror's world remains in its previous consistent state. No corruption occurs. Simply run /mirage pull <dimension> again after reconnecting.

Q: Does Fabric API need to be installed separately? Fabric API is declared as a dependency in fabric.mod.json with * version, meaning it is required. Install it alongside Mirage in the mods/ folder.

License

MIT License — see LICENSE.
