Easily and conveniently resize and rotate blocks (including their block entity renderers and collision boxes) with a single interface.

This is a library mod for Minecraft Forge 1.20.1. Have your Block implement IScalableBlock and/or IRotatableBlock, and it automatically gets scaled/rotated model rendering, BER rendering, and VoxelShape collision, no per-block mixin registration required.

Features

• One interface, everything scaled: implement IScalableBlock, return an SBSProp config, done.
• One interface, everything rotated: implement IRotatableBlock, return an SBSRProp config, and blocks rotate around any axis at any angle.
• Block model rendering: BakedQuad vertices transformed via BakedModel proxy at model bake time, ensuring compatibility with rendering replacers like Embeddium & Oculus.
• Block entity rendering: BERs (chests, signs, etc.) scale and rotate together with their parent block via Mixin injection into BlockEntityRenderDispatcher.
• Collision box scaling & translation: VoxelShape automatically transformed when scaleShape is enabled; intelligently translated to match rotated model center.
• Compound transforms: blocks can implement both interfaces — rotation is applied first, then scaling.
• Configurable pivot: scale and rotate around any anchor point within the block.
• Zero configuration: no mixin config, no JSON, no data-gen. Pure API.

Usage

public class MyBlock extends Block implements IScalableBlock, IRotatableBlock {

    @Override
    public SBSProp getScaleConfig(BlockState state) {
        // Scale to 50% around the block center, including collision
        return new SBSProp(0.5f, 0.5f, 0.5f, 0.5f, 0.5f, 0.5f, true);
    }

    @Override
    public SBSRProp getRotationConfig(BlockState state) {
        // Rotate 45° around Y axis, centered on the block
        return new SBSRProp(45f, Direction.Axis.Y, 0.5f, 0.5f, 0.5f);
    }

    @Override
    public VoxelShape getShape(BlockState state,
                               BlockGetter level,
                               BlockPos pos,
                               CollisionContext ctx) {
        VoxelShape rotatedShape = getTranslatedShape(state, level, pos, ctx,
                                                     super.getShape(state, level, pos, ctx));
        return getScaledShape(state, level, pos, ctx, rotatedShape);
    }
}

SBSProp Parameters

SBSRProp Parameters

Compatible

This mod is designed to be compatible with Embeddium & Oculus. Any incompatibility is welcome to feedback.

Feedback

If you have issues/pr to submit, please first send a brief description about the issue to [email protected], you will be redirected to a gitea website with username & password. You can continue your issues/pr there.
